Possible to flow form complex shape by single chucking with generating metal flow positively. Spline forming without machining, hub forming without welding are the most typical process. Also it is possible to control the material thickness of the specified portion partially for weight reduction and material saving.
V300X | |
---|---|
Number of Axis | 4 |
Axis Control | CNC |
Applications | Clutch Case, Various Drive System parts |
Wheel O.D. | φ300 mm |
Main Spindle, max. | 600 rpm |
Thrust of Roller Unit | X-Axis: 147 kN, Z-Axis: 147 kN |
Stroke of Roller Unit | X-Axis: 150 mm, Z-Axis: 200 mm |
Thrust of tailstock | 441 kN |
Stroke of tailstock | 200 mm |
Motor capacity of main spindle | 100 kW |
Motor capacity of hydraulic unit | 37 kW |
